Ford F-150 XIV (2020-2024) nca Wiring diagrams
This page contains all the electrical diagrams for the component. nca, in which he is found in the car Ford F-150 XIV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram nca (21 of 107)
AM/FM
AUDIO CONTROL PANEL
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO UNIT ANTENNA
AUTOMOTIVE AUDIO BUS (AAB) CABLE
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRDL TX +
FUSE 15
FUSE 28
FUSE 32
GPS/ SATELLITE RADIO/ SECONDARY CELLULAR ANTENNA
GRN/BLU WIRE
GRN/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT A-PILLAR TWEETER SPEAKER
LF SPKR
LR SPKR
MULTI-FUNCTION DISPLAY 8
NCA WIRE
RF SPKR
RR SPKR
SATELLITE
SPLITTER (W/ SATELLITE RADIO)
VBATT
VIO/GRY WIRE
VIO/RED WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> Navigation circuit, 18 speakers (1 of 5) -> NCA WIRE
Wiring diagram nca (22 of 107)
ALERT OUT +
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CREW CAB
DISPLAY
DISPLAY NTSC -
DISPLAY SHIELD
DRDL TX +
GPS
GRN/BLU WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/VIO WIRE
LEFT FRONT OVERHEAD SPEAKER
MIC -
MIC IN -
NAVIGATION SYSTEM
NCA WIRE
PWR
REAR CAMERA CIRCUIT
RIGHT A-PILLAR TWEETER SPEAKER
RIGHT DRIVER SEAT HEADREST SPEAKER
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT OVERHEAD SPEAKER
RIGHT PASSENGER SEAT HEADREST SPEAKER
RIGHT REAR DOOR SPEAKER
SHIELD
STEREO OUT L +
STEREO OUT R +
SUPER CAB
SYNC MODULE (APIM) (CENTER OF DASH)
V BATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VOICE MICROPHONE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, 18 speakers (3 of 5) -> NCA WIRE
Wiring diagram nca (23 of 107)
ALERT OUT +
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CREW CAB
DISPLAY
DISPLAY NTSC -
DISPLAY SHIELD
DRDL TX +
GPS
GRN/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
MIC -
MIC IN -
NAVIGATION SYSTEM
NCA WIRE
PWR
REAR CAMERA CIRCUIT
RIGHT A-PILLAR TWEETER SPEAKER
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
SHIELD
STEREO OUT L +
STEREO OUT R +
SUPER CAB
SYNC MODULE (APIM) (CENTER OF DASH)
V BATT
VIO/GRN WIRE
VIO/GRY WIRE
VOICE MICROPHONE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Navigation circuit, 4 & 6 speakers (2 of 4) -> NCA WIRE
Wiring diagram nca (24 of 107)
A/D CHANNEL 1
A/D CHANNEL 2
A/D CHANNEL 3
A/D RETURN
ALERT IN +
AUDIO FRONT CONTROL MODULE (ACM)
BLK/GRY WIRE
BLU WIRE
BLU/GRY WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DM GND
DM PWR
ETHERNET
GRY/BLU WIRE
GRY/ORG WIRE
ILLUM
LVDS (LOW-VOLTAGE DIFFERENTIAL SIGNALING) COAXIAL CABLE
MEDIA HUB
MULTI-FUNCTION DISPLAY 12
MULTI-FUNCTION DISPLAY 8
NCA WIRE
PWR
SDL H
SDL L
STEERING EFFORT CONTROL MODULE (SECM)
STEREO IN L -
STEREO IN R+
SYNC MODULE (APIM) (CENTER OF DASH)
TPA 1 +
TPA 2 +
TPA+
USB CABLE
USB D-
USB GND
USB VBUS
VIO/GRN WIRE
VIO/GRY WIRE
W/ FLOOR MOUNTED CONSOLE
W/O FLOOR MOUNTED CONSOLE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Navigation circuit, 4 & 6 speakers (3 of 4) -> NCA WIRE
Wiring diagram nca (25 of 107)
A/D CHANNEL 1
A/D CHANNEL 2
A/D CHANNEL 3
A/D RETURN
ALERT IN +
AUDIO FRONT CONTROL MODULE (ACM)
BLK/GRY WIRE
BLU WIRE
BLU/GRY WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DM GND
DM PWR
ETHERNET
GRY/BLU WIRE
GRY/ORG WIRE
ILLUM
LVDS (LOW-VOLTAGE DIFFERENTIAL SIGNALING) COAXIAL CABLE
MEDIA HUB
MULTI-FUNCTION DISPLAY 12
MULTI-FUNCTION DISPLAY 8
NCA WIRE
PWR
SDL H
SDL L
STEERING EFFORT CONTROL MODULE (SECM)
STEREO IN L -
STEREO IN R+
SYNC MODULE (APIM) (CENTER OF DASH)
TPA 1 +
TPA 2 +
TPA+
USB CABLE
USB D-
USB GND
USB VBUS
VIO/GRN WIRE
VIO/GRY WIRE
W/ FLOOR MOUNTED CONSOLE
W/O FLOOR MOUNTED CONSOLE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Navigation circuit, 5 & 7 speakers (3 of 4) -> NCA WIRE
Wiring diagram nca (26 of 107)
AM/FM
AUDIO CONTROL PANEL
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO UNIT ANTENNA
AUTOMOTIVE AUDIO BUS (AAB) CABLE
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DRDL TX +
FUSE 15
FUSE 28
FUSE 32
GPS/ SATELLITE RADIO/ SECONDARY CELLULAR ANTENNA
GRN/BLU WIRE
GRN/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT A-PILLAR TWEETER SPEAKER
LF SPKR
MULTI-FUNCTION DISPLAY 8
NCA WIRE
RF SPKR
SATELLITE
SPLITTER (W/ SATELLITE RADIO)
VBATT
VIO/GRY WIRE
VIO/RED WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> Navigation circuit, 8 speakers (1 of 5) -> NCA WIRE
Wiring diagram nca (27 of 107)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE (BEHIND LEFT REAR SEAT)
AUTOMOTIVE AUDIO BUS (AAB) CABLE
BLK WIRE
BLK/VIO WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER INSTRUMENT PANEL SPEAKER
COMPUTER DATA LINES SYSTEM
CREW CAB
ENABLE/CLIP DETECT
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
IP SPKR +
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LF SPKR
LR SPKR
NCA WIRE
RF SPKR
RR SPKR
SUBWOOFER SPEAKER
SUPER CAB
VBATT
VIO/GRY WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, 8 speakers (2 of 5) -> NCA WIRE
Wiring diagram nca (28 of 107)
ALERT OUT +
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CREW CAB
DISPLAY
DISPLAY NTSC -
DISPLAY SHIELD
DRDL TX +
GPS
GRN/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
MIC -
MIC IN -
NAVIGATION SYSTEM
NCA WIRE
PWR
REAR CAMERA CIRCUIT
RIGHT A-PILLAR TWEETER SPEAKER
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
SHIELD
STEREO OUT L +
STEREO OUT R +
SUPER CAB
SYNC MODULE (APIM) (CENTER OF DASH)
V BATT
VIO/GRN WIRE
VIO/GRY WIRE
VOICE MICROPHONE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, 8 speakers (3 of 5) -> NCA WIRE
Wiring diagram nca (29 of 107)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/GRY WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DISPLAY NTSC + DISPLAY SHIELD
DISPLAY NTSC -
DISPLAY SHIELD
FUSE 15
FUSE 25
GRN/BLU WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
MICRO -
NCA WIRE
REAR PARKING AID CAMERA
SYNC MODULE (APIM) (CENTER OF DASH)
VIO/WHT WIRE
VPWR
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
Go to component -> Rear camera circuit, level 2 -> NCA WIRE
Wiring diagram nca (30 of 107)
BLK WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN/WHT WIRE
CELLULAR
COMPUTER DATA LINES SYSTEM
ETHERNET
FUSE 8
GPS
GPS/SATELLITE RADIO/ SECONDARY CELLULAR ANTENNA
HOT AT ALL TIMES
NCA WIRE
PRIMARY CELLULAR ANTENNA
SECONDARY CELLULAR
TELEMATIC CONTROL UNIT (TCU) MODULE
VBATT
VIO/WHT WIRE
WHT/ORG WIRE
YEL/RED WIRE
Go to component -> Telematics circuit -> NCA WIRE
