Ford F-150 XIV (2020-2024) mirror circuit Wiring diagram
This page shows the only wiring diagram for the component.mirror circuit, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror circuit (1 of 1)
BLIS INDICATOR
BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM) (LOWER FRONT OF DRIVER DOOR)
DRIVER DOOR WINDOW CONTROL SWITCH
DRV HEATED
DRV MIRR HORZ POT
DRV MIRR MTR COM
DRV MIRR VERT POT
DRV MIRROR MTR HORZ
DRV MIRROR MTR VERT
DRV PUDDLE
DRV TURN
ELECTROCHROMIC
EXT MIRR POT FEED
EXTERIOR MIRROR TELESCOPE SWITCH
FOLD OUT
FOLD-IN
FUSE 23
FUSE 6
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEATER
HOT AT ALL TIMES
ILLUM
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LIN BUS
MIRROR CIRCUIT
MIRRORS CIRCUIT
PARK
PUDDLE
RTN
SET 1
SET 2
SET 3
SIG RTN
SPOT
TELESCOPING
TURN
VBATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ FOLDING MIRRORS
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> MIRROR CIRCUIT
