Ford F-150 XIV (2020-2024) middle center stack instrument panel switch wiring diagram
This page shows the only wiring diagram for the component.middle center stack instrument panel switch, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
middle center stack instrument panel switch wiring diagram (1 of 1)
ADJUSTABLE PEDAL CONTROL SWITCH
ALL TERRAIN CONTROL MODULE (ATCM)
AUDIO CONTROL PANEL
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
DRIVER STATUS MONITOR CAMERA MODULE (CMR)
GEAR SHIFT MODULE (GSM)
GLOVE COMPARTMENT LAMP
HEADLAMP CONTROL MODULE (HCM)
HEADLAMP SWITCH
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LEFT CENTER STACK INSTRUMENT PANEL SWITCH
LEFT FRONT FOOTWELL LAMP
MEDIA BIN POWER POINT 1
MEDIA BIN POWER POINT 2
MIDDLE CENTER STACK INSTRUMENT PANEL SWITCH
MULTI-FUNCTION DISPLAY 8
PARKING BRAKE SWITCH
PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER
POWER TAILGATE RELEASE/ POWER TO THE BOX SWITCH
PRO TRAILER BACKUP ASSIST CONTROL KNOB
REMOTE DATA LINK CONNECTOR (DLC)
RIGHT CENTER STACK INSTRUMENT PANEL SWITCH
RIGHT FRONT FOOTWELL LAMP
STEERING ANGLE SENSOR MODULE (SASM)
STEERING COLUMN CONTROL MODULE (SCCM)
TRAILER BRAKE CONTROL SWITCH
USB CHARGE PORT
W/ COLUMN SHIFTER
W/ FLOOR SHIFTER
WIRELESS ACCESSORY CHARGING MODULE (WACM)
Go to component -> Ground distribution circuit (4 of 10) -> MIDDLE CENTER STACK INSTRUMENT PANEL SWITCH
