Ford F-150 XIV (2020-2024) left front multi-contour control pump Wiring diagram
This page shows the only wiring diagram for the component.left front multi-contour control pump, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front multi-contour control pump (1 of 1)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT CUSHION MODULE
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG)
FEED
FRONT HEATED SEATS CIRCUIT
FUSE 134
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT FRONT MULTI-CONTOUR CONTROL PUMP
MICRO -
MS CAN +
MULTI- CONTOUR SEAT RELAY
RTN
VIO/ORG WIRE
VPWR
WHT/VIO WIRE
YEL WIRE
Go to component -> Power seats circuit, 10-way driver seat (2 of 2) -> LEFT FRONT MULTI-CONTOUR CONTROL PUMP
