Ford F-150 XIV (2020-2024) left front door lock switch Wiring diagrams
This page contains all the electrical diagrams for the component. left front door lock switch, in which he is found in the car Ford F-150 XIV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front door lock switch (1 of 2)
ANT
BLK WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN/GRN WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM) (LOWER FRONT OF DRIVER DOOR)
GRN/ORG WIRE
GROUND DISTRIBUTION SYSTEM
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
ILLUM
INTRUSION SENSOR
K LINE
KEYLESS ENTRY REAR ANTENNA
LEDS
LEFT FRONT DOOR LOCK SWITCH
LIN 3
LOCK
PASSIVE ANTI-THEFT SYSTEM (PATS) CENTER ANTENNA
RADIO TRANSCEIVER MODULE (RTM)
SET 1
SET 2
SET 3
SIGRTN
UNLOCK
UNLOCK LOCK
VBATT
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ MEMORY
W/O MEMORY
W/O REMOTE TAILGATE RELEASE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Forced entry circuit (3 of 5) -> LEFT FRONT DOOR LOCK SWITCH
