Ford F-150 XIV (2020-2024) left front door ambient lamp Wiring diagrams
This page contains all the electrical diagrams for the component. left front door ambient lamp, in which he is found in the car Ford F-150 XIV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front door ambient lamp (1 of 2)
AMB LTG (FET)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
FLOOR CONSOLE CUPHOLDER AMBIENT LAMP
FLOOR CONSOLE FRONT BIN LAMP
FLOOR CONSOLE REAR BACK PANEL LAMP
FLOOR CONSOLE REAR BIN LAMP
FUSE 1
FUSE 202
GRN/BLU WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR AMBIENT LAMP
LEFT FRONT FOOTWELL LAMP
LEFT FRONT SEAT LAMP (REAR FOOTWELL)
LEFT REAR DOOR AMBIENT LAMP
LIN LIN
MICRO -
NCA WIRE
POWER
PUDDLE LAMP (FET)
PWR
RED WIRE
RIGHT FRONT DOOR AMBIENT LAMP
RIGHT FRONT FOOTWELL LAMP
RIGHT FRONT SEAT LAMP (REAR FOOTWELL)
RIGHT REAR DOOR AMBIENT LAMP
WHT/GRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (2 of 4) -> LEFT FRONT DOOR AMBIENT LAMP
Wiring diagram left front door ambient lamp (2 of 2)
8 WAY SEAT 10 WAY SEAT
AUDIO FRONT CONTROL MODULE (ACM)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/ORG WIRE
CLOCKSPRING
DISPLAY UNIT
DRIVER DOOR MODULE (DDM)
DRIVER FRONT SEAT CUSHION MODULE
DRIVER FRONT SEAT MODULE (DSM)
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG)
DRIVER SEAT POSITION SENSOR
GATEWAY MODULE A (GWM)
HORN SWITCH
IMAGE PROCESSING MODULE A (IPMA)
KEYLESS ENTRY KEYPAD
LEFT EXTERIOR MIRROR
LEFT FRONT DOOR AMBIENT LAMP
LEFT FRONT DOOR LATCH
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT BELT BUCKLE
LEFT FRONT SEAT CONTROL SWITCH
LEFT FRONT SEAT LAMP (REAR FOOTWELL)
LEFT POWER RUNNING BOARD (PRB) MOTOR
LEFT SCUFF PLATE LAMP
LEFT STEERING WHEEL SWITCH
NCA WIRE
REMOTE DATA LINK CONNECTOR (DLC)
RIGHT STEERING WHEEL SWITCH
SYNC MODULE (APIM)
TRAILER BRAKE CONTROL MODULE (TBM)
TRAILER MODULE (TRM)
W/ ADAPTIVE STEERING
W/ HEATED SEATS
W/ MEMORY
W/ MULTI-CONTOUR SEAT
W/O ADAPTIVE STEERING
Go to component -> Ground distribution circuit (5 of 10) -> LEFT FRONT DOOR AMBIENT LAMP
