Ford F-150 XIV (2020-2024) hall effect power Wiring diagram
This page shows the only wiring diagram for the component.hall effect power, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hall effect power (1 of 1)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT MODULE (DSM)
FUSE 30
GRN WIRE
GRN/BRN WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HALL EFFECT POWER
HOT AT ALL TIMES
LEFT KICK SWITCH
LEFT POWER RUNNING BOARD (PRB) MOTOR (ON FRONT OF RUNNING BOARD)
LEFT RB DEPLOY
LEFT RB HALL EFFECT SIG
LEFT RB STOW
RED WIRE
RIGHT KICK SWITCH
RIGHT POWER RUNNING BOARD (PRB) MOTOR (ON FRONT OF RUNNING BOARD)
RIGHT RB DEPLOY
RIGHT RB HALL EFFECT SIG
RIGHT RB STOW
SEATS SYSTEM
SIG RTN
VBATT
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
YEL/VIO WIRE
Go to component -> Retractable running boards circuit -> HALL EFFECT POWER
