Ford F-150 XIV (2020-2024) ebp sw 3 ebp sw 5 Wiring diagram
This page shows the only wiring diagram for the component.ebp sw 3 ebp sw 5, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ebp sw 3 ebp sw 5 (1 of 1)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
EBP SW 2
EBP SW 3 EBP SW 5
EBP SW 4 EBP SW 1
EBP SW 6
FUSE 13
FUSE 28
FUSE 29
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HS CAN FD -
INSTRUMENT PANEL CLUSTER (IPC)
LEDS
LEFT PARKING BRAKE ACTUATOR MOTOR
MTR A EPB LT
MTR A EPB RT
MTR B
MTR B EPB LT
MTR B EPB RT
ORG/ WIRE
PARKING BRAKE SWITCH
RIGHT PARKING BRAKE ACTUATOR MOTOR
SYSTEM
VALVE B+
VBATT
VIO WIRE
VIO/GRN WIRE
W/ STANDARD DUTY SUSPENSION PERFORMANCE SUSPENSION W/ OFF ROAD SUSPENSION
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Electric parking brake circuit -> EBP SW 3 EBP SW 5
