Ford F-150 XIV (2020-2024) driver side driver status monitor led Wiring diagram
This page shows the only wiring diagram for the component.driver side driver status monitor led, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side driver status monitor led (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
CAMERA
COAX CABLE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE DRIVER STATUS MONITOR LED
DRIVER STATUS MONITOR CAMERA
DRIVER STATUS MONITOR CAMERA MODULE (CMR)
FUSE 31
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN FD -
IR LED +
PASSENGER SIDE DRIVER STATUS MONITOR LED
VPWR
WHT/GRN WIRE
WHT/RED WIRE
YEL/ORG WIRE
Go to component -> Driver monitoring system circuit -> DRIVER SIDE DRIVER STATUS MONITOR LED
