Ford F-150 XIV (2020-2024) active dmpr fr hi Wiring diagram

ACTIVE DMPR FL HI ACTIVE DMPR FL LO ACTIVE DMPR FR HI ACTIVE DMPR FR LO ACTIVE DMPR RL HI ACTIVE DMPR RL LO ACTIVE DMPR RR HI ACTIVE DMPR RR LO BATTERY JUNCTION BOX (BCMC) BLK WIRE BLU/BRN WIRE BLU/ORG WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM EXCEPT HYBRID EXCEPT HYBRID RAPTOR EXCEPT RAPTOR FL SIG FR SIG FUSE 14 GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE HOT W/ RUN/START RELAY ENERGIZED HS CAN FD - LEFT FRONT HYDRAULIC SOLENOID VALVE LEFT FRONT SUSPENSION HEIGHT SENSOR LEFT REAR HYDRAULIC SOLENOID VALVE LEFT REAR SUSPENSION HEIGHT SENSOR NCA WIRE RAPTOR RIGHT FRONT HYDRAULIC SOLENOID VALVE RIGHT FRONT SUSPENSION HEIGHT SENSOR RIGHT REAR HYDRAULIC SOLENOID VALVE RIGHT REAR SUSPENSION HEIGHT SENSOR RL SIG RR SIG SIGRTN VEHICLE DYNAMICS CONTROL MODULE (VDM) VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE VPWR VREF WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/ORG WIRE
