Ford F-150 XIV (2020-2024) 8 way power seat 10 way power seat Wiring diagram
This page shows the only wiring diagram for the component.8 way power seat 10 way power seat, which is found in the car Ford F-150 XIV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 8 way power seat 10 way power seat (1 of 1)
8 WAY POWER SEAT 10 WAY POWER SEAT
AUXILIARY BATTERY ISOLATOR
AUXILIARY BOX
AUXILIARY BOX (3.5L TURBO HYBRID)
AUXILIARY STUD BOX
BATTERY
BATTERY MONITORING SENSOR
BELT-DRIVEN INTEGRATED STARTER GENERATOR
DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE
DRIVER FRONT SEAT MODULE (DSM)
ENGINE COOLING FAN RELAY #1
ENGINE COOLING FAN RELAY #2
FUEL PUMP RELAY
FUSE 1
FUSE 103
FUSE 201
FUSE 202
FUSE 204
FUSE 208
FUSE 211
FUSE 213
FUSE 3
FUSE 30
FUSE 31
FUSE 36
FUSE 64
FUSE 80
FUSE 82
GENERATOR
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
HORN RELAY
LEFT FRONT SEAT CONTROL SWITCH
POLICE
POWER STEERING CONTROL MODULE (PSCM)
RED WIRE
RIGHT FRONT SEAT CONTROL SWITCH
STARTER MOTOR
STARTER RELAY
TO BODY CONTROL MODULE (BCM) (DIAGRAM 6 OF 12)
TO DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER (DIAGRAM 8 OF 12)
TO ENGINE COOLING FAN RELAY 1 (DIAGRAM 2 OF 12)
TRANSFER CASE CONTROL MODULE (TCCM)
VIO WIRE
VIO/RED WIRE
W/ MEMORY
W/O MEMORY
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 12) -> 8 WAY POWER SEAT 10 WAY POWER SEAT
