Tire pressure monitoring circuit for Ford F-150 XIII facelift (2017-2020)

Tire pressure monitoring circuit

Get access

BLK/BLU WIRE BLU WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM FUSE 32 GRN/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) K LINE MICRO - MS CAN + RADIO TRANSCEIVER MODULE (RTM) (UPPER RIGHT REAR OF CAB) VBATT VIO/ORG WIRE VIO/RED WIRE WHT WIRE WHT/GRN WIRE
