Car Wiring Diagrams for Tailgate release circuit for Ford F-150 XIII facelift (2017-2020)

BATTERY JUNCTION BOX (BJB) BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN/YEL WIRE CAN (+) COMPUTER DATA LINES SYSTEM DECKLID/ LIFTGATE RELAY FUSE 16 FUSE 4 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) MICRO - TAILGATE AJAR CAN + TAILGATE AJAR SWITCH TAILGATE LATCH ACTUATOR TAILGATE RELEASE TAILGATE RELEASE SWITCH W/O REMOTE TAILGATE RELEASE WHT WIRE WHT/GRN WIRE YEL/ORG WIRE
