Sliding rear window circuit for Ford F-150 XIII facelift (2017-2020)
Sliding rear window circuit
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/YEL WIRE
CLOSE
FUSE 102
FUSE 23
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
POWER SLIDING REAR WINDOW CLOSE RELAY
POWER SLIDING REAR WINDOW OPEN RELAY
REAR POWER SLIDING WINDOW MOTOR
REAR POWER SLIDING WINDOW SWITCH
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
YEL WIRE
YEL/GRN WIRE
