Power seats circuit, 10-way passenger seat for Ford F-150 XIII facelift (2017-2020)

Power seats circuit, 10-way passenger seat (1 of 2)

F-150 Ford XIII facelift (2017-2020): Power seats circuit, 10-way passenger seat (1 of 2)

Get access

AFT BATTERY JUNCTION BOX (BJB) BLK WIRE BLU WIRE BRN WIRE DEFLATE DOWN FORE/ FRONT HEIGHT FUSE 21 GRN WIRE GRN/VIO WIRE GRY WIRE HORIZONTAL HOT AT ALL TIMES INCLINE INFLATE LUMBAR MODE SELECT ORG/ WIRE PASSENGER SEAT FRONT HEIGHT MOTOR PASSENGER SEAT HORIZONTAL MOTOR PASSENGER SEAT LUMBAR MOTOR PASSENGER SEAT REAR HEIGHT MOTOR PASSENGER SEAT RECLINER MOTOR PASSENGER SIDE FRONT SEAT CONTROL SWITCH REAR HEIGHT RECLINE RED WIRE VIO WIRE W/O MULTI-CONTOUR SEAT W/ MULTI-CONTOUR SEAT WHT WIRE WHT/ORG WIRE YEL WIRE

Power seats circuit, 10-way passenger seat (2 of 2)

F-150 Ford XIII facelift (2017-2020): Power seats circuit, 10-way passenger seat (2 of 2)

Get access

BATTERY JUNCTION BOX (BJB) BATTERY SAVER RELAY BLK/BLU WIRE BLK/VIO WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM DRIVER MULTI-CONTOUR SEAT MODULE FEED FUSE 1 FUSE 88 GRN/ORG WIRE GRN/VIO WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES MS CAN + MULTI- CONTOUR SEAT RELAY NCA WIRE PASSENGER MULTI- CONTOUR SEAT MODULE RIGHT FRONT MULTI-CONTOUR CONTROL PUMP RTN VIO/ORG WIRE VPWR W/ MULTI-CONTOUR SEAT WHT/ORG WIRE YEL WIRE YEL/GRN WIRE
