Power seats circuit, 10-way driver seat for Ford F-150 XIII facelift (2017-2020)
Power seats circuit, 10-way driver seat (1 of 2)
AFT
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BRN WIRE
DEFLATE
DOWN
DRIVER SEAT FRONT HEIGHT MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT LUMBAR MOTOR
DRIVER SEAT REAR HEIGHT MOTOR
DRIVER SEAT RECLINER MOTOR
DRIVER SIDE FRONT SEAT CONTROL SWITCH
FORE/
FRONT HEIGHT
FUSE 27
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HORIZONTAL
HOT AT ALL TIMES
INCLINE
INFLATE
INFLATE RECLINE
LUMBAR
MODE SELECT
ORG/ WIRE
REAR HEIGHT
RECLINE
RED WIRE
VIO WIRE
W/O MULTI-CONTOUR SEAT W/ MULTI-CONTOUR SEAT
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Power seats circuit, 10-way driver seat (2 of 2)
BATTERY JUNCTION BOX (BJB)
BATTERY SAVER RELAY
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DRIVER MULTI-CONTOUR SEAT MODULE
FEED
FUSE 1
FUSE 88
GRN/ORG WIRE
GRN/VIO WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT FRONT MULTI-CONTOUR CONTROL PUMP
MS CAN +
MULTI- CONTOUR SEAT RELAY
NCA WIRE
PASSENGER MULTI- CONTOUR SEAT MODULE
RTN
VIO/ORG WIRE
VPWR
W/ MULTI-CONTOUR SEAT
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
