Electrochromic mirror circuit, w/ lane keeping assist w/o collision avoidance detection system for Ford F-150 XIII facelift (2017-2020)
Electrochromic mirror circuit, w/ lane keeping assist w/o collision avoidance detection system
ACTIVE PARK ASSIST/LANE KEEPING SWITCH
AUTO DIMMING INTERIOR MIRROR
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/VIO WIRE
CAMERA WINDSHIELD DEFROST HEATER
CENTER OF WINDSHIELD)
COMPUTER DATA LINES SYSTEM
EC+
FUSE 36
GRN WIRE
GRN/ORG WIRE
GRY/BLU WIRE
HEATER
HOT W/ IGNITION RELAY ENERGIZED
LANE DEPARTURE
LEFT EXTERIOR MIRROR
POWER DISTRIBUTION SYSTEM
VPWR
WHT WIRE
