Passive anti-theft circuit for Ford F-150 XIII facelift (2017-2020)
Passive anti-theft circuit
ANT
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
CAN (+)
COMPUTER DATA LINES SYSTEM
ECU DRV (PCM WAKE UP) (FET)
FUSE 76
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/VIO WIRE
HALF BRIDGE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
KEYLESS ENTRY REAR ANTENNA
LIN 1
MICRO -
PASSIVE ANTI-THEFT SYSTEM (PATS) REAR ANTENNA
PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER
PASSIVE ANTI-THEFT SYSTEM CENTER (PATS) ANTENNA
PCM WAKE
PROTECT 1 ANTENNA HI(HB)
PROTECT 1 ANTENNA LO(HB)
PROTECT 2 ANTENNA HI(HB)
PROTECT 2 ANTENNA LO(HB)
PWR GND
VIO/ORG WIRE
W/ CENTER CONSOLE
W/ REMOTE TAILGATE RELEASE W/O REMOTE TAILGATE RELEASE
W/O CENTER CONSOLE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRN WIRE
