Ford F-150 XIII facelift (2017-2020) variable blower ctrl motor + Wiring diagram
This page shows the only wiring diagram for the component.variable blower ctrl motor +, which is found in the car Ford F-150 XIII facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram variable blower ctrl motor + (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BLOWER MOTOR
BLOWER MOTOR CONTROL MODULE
BLOWER MOTOR RELAY
BLOWER RELAY
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DEFROST REQUEST
DRIVER SIDE FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR
DRIVER SIDE REGISTER AIR DISCHARGE TEMPERATURE SENSOR
DRIVER SIDE TEMPERATURE DOOR ACTUATOR
DRV HEATED SEAT ELEMENT
DRV HEATER FEED
EVAP
FEEDBACK
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 20
FUSE 28
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT CUSHION HEATER MAT
LH FLR SENS 1
LH FRT SENS 1
MOTOR
MS CAN +
NCA WIRE
PASS HEATED SEAT ELEMENT
PASS HEATER FEED
PASS SEAT NTC SENSE
PTC BANK 1
PTC BANK 2
PTC BANK 3
RED WIRE
RIGHT FRONT SEAT CUSHION HEATER MAT
SEATS SYSTEM
SIG RTN
VARIABLE BLOWER CTRL MOTOR +
VBATT
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VREF
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Manual a/c circuit (1 of 5) -> VARIABLE BLOWER CTRL MOTOR +
