Ford F-150 XIII facelift (2017-2020) tailgate release switch Wiring diagrams
This page contains all the electrical diagrams for the component. tailgate release switch, in which he is found in the car Ford F-150 XIII facelift (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
tailgate release switch wiring diagram (1 of 4)
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CAN (+)
CENTRAL LOCK RELAY
CENTRAL UNLOCK RELAY
COMPUTER DATA LINES SYSTEM
CONTROL
CREW CAB
DECKLID/ LIFTGATE RELAY
DRIVER/FUEL FLAP UNLOCK RELAY
FROM FUSE 34 (DIAGRAM 1 OF 4)
FROM KEYPAD ILLUM (FET) (DIAGRAM 1 OF 4)
FUSE 16
FUSE 24
FUSE 3
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR LATCH
LEFT REAR DOOR LATCH
MICRO -
REGULAR CAB, SUPER CAB
RIGHT FRONT DOOR LATCH
RIGHT REAR DOOR LATCH
STANDARD CAB/ SUPER CAB
SUPER CREW CAB
TAILGATE LATCH ACTUATOR
TAILGATE LOCK ACTUATOR
TAILGATE RELEASE
TAILGATE RELEASE ACTUATOR
TAILGATE RELEASE SWITCH
W/ REMOTE TAILGATE RELEASE W/O REMOTE TAILGATE RELEASE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (4 of 4) -> TAILGATE RELEASE SWITCH
tailgate release switch wiring diagram (2 of 4)
