Ford F-150 XIII facelift (2017-2020) nox 11 sensor module Wiring diagram
This page shows the only wiring diagram for the component.nox 11 sensor module, which is found in the car Ford F-150 XIII facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram nox 11 sensor module (1 of 1)
2.7L TURBO
2.7L TURBO 5.0L FLEX FUEL 3.3L FLEX FUEL, 3.5L TURBO EXCEPT 3.0L TURBO DIESEL
3.0L TURBO DIESEL
3.3L FLEX FUEL
5.0L FLEX FUEL
BATTERY JUNCTION BOX (BJB)
BLU WIRE
FROM FUSE 104 (DIAGRAM 2 OF 12)
FUSE 105
FUSE 24
FUSE 35
FUSE 38
FUSE 89
GLOW PLUG CONTROL MODULE (GPCM)
GRY/BLU WIRE
HEATED WIPER PARK RELAY
IGNITION COIL ON PLUG 1
IGNITION COIL ON PLUG 2
IGNITION COIL ON PLUG 3
IGNITION COIL ON PLUG 4
IGNITION COIL ON PLUG 5
IGNITION COIL ON PLUG 6
IGNITION COIL ON PLUG 7
IGNITION COIL ON PLUG 8
IGNITION TRANSFORMER CAPACITOR
MASS AIRFLOW, INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR
NOX 11 SENSOR MODULE
NOX 12 SENSOR MODULE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
REDUCTANT LEVEL SENSOR
RUNNING BOARD CONTROL MODULE (RBM)
TELESCOPING EXTERIOR REAR VIEW MIRROR EXTEND RELAY
TELESCOPING EXTERIOR REAR VIEW MIRROR RETRACT RELAY
TO FUSE 37 (DIAGRAM 6 OF 12)
TO MULTI- CONTOUR SEAT RELAY (DIAGRAM 4 OF 12)
TRAILER BRAKE CONTROL (TBM) MODULE
TRAILER TOW PARK LAMP RELAY
VIO WIRE
VIO/RED WIRE
WIPER RELAY
YEL/BLU WIRE
Go to component -> Power distribution circuit (3 of 12) -> NOX 11 SENSOR MODULE
