Ford F-150 XIII facelift (2017-2020) center stack switch Wiring diagrams
This page contains all the electrical diagrams for the component. center stack switch, in which he is found in the car Ford F-150 XIII facelift (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram center stack switch (1 of 7)
2 HI
3.0L TURBO DIESEL
4 AUTO
4 HI
4 LO
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER STACK SWITCH
CLUTCH
CLUTCH CTRL
COMPUTER DATA LINES SYSTEM
DIFF LOCK CTRL
ELECTRONIC LOCKING DIFFERENTIAL (ELD) FIELD COIL
EXCEPT PHANTOM/ RAPTOR
FUSE 13
FUSE 17
FUSE 29
FUSE 63
FUSE 71
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HI TO LOW
HILL DESCENT
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
INTEGRATED WHEEL END (IWE) SOLENOID
LOCKER MODE SW
LOW TO HI
MODE SELECT SWITCH (MSS)
MSS RTN
MTR-CCW
MTR-CW
NCA WIRE
PHANTOM/ RAPTOR
POS 1
POS 1 MTR
POS 2
POS 2 MTR
POS 3
POS 3 MTR
POS 4
POS 4 MTR
POS RTN
POWER DISTRIBUTION SYSTEM
RAPTOR
RED WIRE
SOLENOID
TCS ON/OFF
TRANSFER CASE ASSEMBLY (LEFT REAR OF TRANSMISSION)
TRANSFER CASE CONTROL MODULE (TCCM)
VBATT
VIO/GRN WIRE
VIO/GRY WIRE
VPWR
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> 2.7l turbo, 4wd circuit -> CENTER STACK SWITCH
Wiring diagram center stack switch (2 of 7)
2 HI
3.0L TURBO DIESEL
4 AUTO
4 HI
4 LO
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER STACK SWITCH
CLUTCH
CLUTCH CTRL
COMPUTER DATA LINES SYSTEM
DIFF LOCK CTRL
ELECTRONIC LOCKING DIFFERENTIAL (ELD) FIELD COIL
EXCEPT PHANTOM/ RAPTOR
FUSE 13
FUSE 17
FUSE 29
FUSE 63
FUSE 71
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HI TO LOW
HILL DESCENT
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
INTEGRATED WHEEL END (IWE) SOLENOID
LOCKER MODE SW
LOW TO HI
MODE SELECT SWITCH (MSS)
MSS RTN
MTR-CCW
MTR-CW
NCA WIRE
PHANTOM/ RAPTOR
POS 1
POS 1 MTR
POS 2
POS 2 MTR
POS 3
POS 3 MTR
POS 4
POS 4 MTR
POS RTN
POWER DISTRIBUTION SYSTEM
RAPTOR
RED WIRE
SOLENOID
TCS ON/OFF
TRANSFER CASE ASSEMBLY (LEFT REAR OF TRANSMISSION)
TRANSFER CASE CONTROL MODULE (TCCM)
VBATT
VIO/GRN WIRE
VIO/GRY WIRE
VPWR
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> 3.0l turbo diesel, 4wd circuit -> CENTER STACK SWITCH
Wiring diagram center stack switch (3 of 7)
2 HI
3.0L TURBO DIESEL
4 AUTO
4 HI
4 LO
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER STACK SWITCH
CLUTCH
CLUTCH CTRL
COMPUTER DATA LINES SYSTEM
DIFF LOCK CTRL
ELECTRONIC LOCKING DIFFERENTIAL (ELD) FIELD COIL
EXCEPT PHANTOM/ RAPTOR
FUSE 13
FUSE 17
FUSE 29
FUSE 63
FUSE 71
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HI TO LOW
HILL DESCENT
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
INTEGRATED WHEEL END (IWE) SOLENOID
LOCKER MODE SW
LOW TO HI
MODE SELECT SWITCH (MSS)
MSS RTN
MTR-CCW
MTR-CW
NCA WIRE
PHANTOM/ RAPTOR
POS 1
POS 1 MTR
POS 2
POS 2 MTR
POS 3
POS 3 MTR
POS 4
POS 4 MTR
POS RTN
POWER DISTRIBUTION SYSTEM
RAPTOR
RED WIRE
SOLENOID
TCS ON/OFF
TRANSFER CASE ASSEMBLY (LEFT REAR OF TRANSMISSION)
TRANSFER CASE CONTROL MODULE (TCCM)
VBATT
VIO/GRN WIRE
VIO/GRY WIRE
VPWR
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> 3.3l flex fuel, 4wd circuit -> CENTER STACK SWITCH
Wiring diagram center stack switch (4 of 7)
2 HI
3.0L TURBO DIESEL
4 AUTO
4 HI
4 LO
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER STACK SWITCH
CLUTCH
CLUTCH CTRL
COMPUTER DATA LINES SYSTEM
DIFF LOCK CTRL
ELECTRONIC LOCKING DIFFERENTIAL (ELD) FIELD COIL
EXCEPT PHANTOM/ RAPTOR
FUSE 13
FUSE 17
FUSE 29
FUSE 63
FUSE 71
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HI TO LOW
HILL DESCENT
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
INTEGRATED WHEEL END (IWE) SOLENOID
LOCKER MODE SW
LOW TO HI
MODE SELECT SWITCH (MSS)
MSS RTN
MTR-CCW
MTR-CW
NCA WIRE
PHANTOM/ RAPTOR
POS 1
POS 1 MTR
POS 2
POS 2 MTR
POS 3
POS 3 MTR
POS 4
POS 4 MTR
POS RTN
POWER DISTRIBUTION SYSTEM
RAPTOR
RED WIRE
SOLENOID
TCS ON/OFF
TRANSFER CASE ASSEMBLY (LEFT REAR OF TRANSMISSION)
TRANSFER CASE CONTROL MODULE (TCCM)
VBATT
VIO/GRN WIRE
VIO/GRY WIRE
VPWR
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> 3.5l turbo, 4wd circuit -> CENTER STACK SWITCH
Wiring diagram center stack switch (5 of 7)
2 HI
3.0L TURBO DIESEL
4 AUTO
4 HI
4 LO
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER STACK SWITCH
CLUTCH
CLUTCH CTRL
COMPUTER DATA LINES SYSTEM
DIFF LOCK CTRL
ELECTRONIC LOCKING DIFFERENTIAL (ELD) FIELD COIL
EXCEPT PHANTOM/ RAPTOR
FUSE 13
FUSE 17
FUSE 29
FUSE 63
FUSE 71
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HI TO LOW
HILL DESCENT
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
INTEGRATED WHEEL END (IWE) SOLENOID
LOCKER MODE SW
LOW TO HI
MODE SELECT SWITCH (MSS)
MSS RTN
MTR-CCW
MTR-CW
NCA WIRE
PHANTOM/ RAPTOR
POS 1
POS 1 MTR
POS 2
POS 2 MTR
POS 3
POS 3 MTR
POS 4
POS 4 MTR
POS RTN
POWER DISTRIBUTION SYSTEM
RAPTOR
RED WIRE
SOLENOID
TCS ON/OFF
TRANSFER CASE ASSEMBLY (LEFT REAR OF TRANSMISSION)
TRANSFER CASE CONTROL MODULE (TCCM)
VBATT
VIO/GRN WIRE
VIO/GRY WIRE
VPWR
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> 5.0l flex fuel, 4wd circuit -> CENTER STACK SWITCH
Wiring diagram center stack switch (6 of 7)
ACTIVE PARK ASSIST/ LANE KEEPING SWITCH
ADJUSTABLE PEDAL CONTROL SWITCH
AUTO START STOP DEACTIVATION SWITCH
BATTERY ENERGY CONTROL MODULE B (BECMB)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BRAKE SHIFT INTERLOCK
CENTER STACK SWITCH
FLOOR SHIFTER
FRONT CONTROL/DISPLAY INTERFACE MODULE (FCDIM)
FRONT CONTROLS INTERFACE MODULE (FCIM)
GATEWAY MODULE A (GWM)
GLOVE COMPARTMENT LAMP
HAZARD/SNOW PLOW/360 CAMERA SWITCH
HEAD-UP DISPLAY (HUD) MODULE
HEADLAMP SWITCH
HEATED STEERING WHEEL MODULE (HSWM)
IGNITION SWITCH
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL POWER POINT 1
INSTRUMENT PANEL POWER POINT 2
LEFT FRONT FOOTWELL LAMP
MODE SELECT SWITCH (MSS)
NCA WIRE
PARKING BRAKE SWITCH
PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER
PRO TRAILER BACKUP ASSIST CONTROL KNOB
REAR PARKING AID CAMERA
RIGHT FRONT FOOTWELL LAMP
RIGHT INSTRUMENT PANEL AMBIENT LAMP
SPOT LAMP CONTROL MODULE
SPOT LAMP SWITCH
STEERING COLUMN LOCK MODULE
TRAILER BRAKE CONTROL MODULE (TBM)
W/ COLUMN SHIFTER
W/ PEPS W/O REMOTE TAILGATE RELEASE
W/ PEPS, REMOTE TAILGATE RELEASE
W/ TELEMATICS
W/O CENTER CONSOLE
W/O PEPS
Go to component -> Ground distribution circuit (4 of 8) -> CENTER STACK SWITCH
Wiring diagram center stack switch (7 of 7)
ADJUSTABLE PEDAL CONTROL SWITCH
AUXILIARY SWITCHES (W/ SPARE ACCESSORY SWITCH)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
CENTER STACK SWITCH
CLOCKSPRING
DOWNSHIFT PADDLE SWITCH
FLOOR CONSOLE LAMP
GRY WIRE
HEATED REAR SEAT SWITCH
IGNITION SWITCH
LEFT STEERING WHEEL MULTI-FUNCTION SWITCH
NCA WIRE
RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH
STEERING WHEEL)
STOP LAMP SWITCH
UPSHIFT PADDLE SWITCH
VIO/GRY WIRE
W/ CRUISE CONTROL W/O CRUISE CONTROL
W/ PHANTOM, RAPTOR
Go to component -> Instrument illumination circuit (2 of 2) -> CENTER STACK SWITCH
