Sliding rear window circuit for Ford F-150 XIII (2014-2018)

Sliding rear window circuit

Get access

BATTERY JUNCTION BOX (BJB) BLK/VIO WIRE BLK/YEL WIRE BODY CONTROL MODULE (BCM) BRN/VIO WIRE BRN/YEL WIRE CLOSE FUSE 23 FUSE 74 HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED POWER SLIDING REAR WINDOW CLOSE RELAY POWER SLIDING REAR WINDOW OPEN RELAY REAR POWER SLIDING WINDOW MOTOR REAR POWER SLIDING WINDOW SWITCH VIO WIRE VIO/BRN WIRE VIO/ORG WIRE YEL WIRE YEL/ORG WIRE YEL/RED WIRE
