Car Wiring Diagrams for Parking assistant circuit for Ford F-150 XIII (2014-2018)

APA ENABLE/ AUTO PARK/LANE KEEPING SWITCH BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM FRONT PARK AID SENS POWER (HB) FUSE 13 GRN WIRE GRN/WHT WIRE GROUND DISTRIBUTION SYSTEM GRY/ORG WIRE GRY/RED WIRE HALF BRIDGE HOT AT ALL TIMES LEFT FRONT PARKING AID SENSOR LEFT INNER PARKING AID SENSOR LEFT OUTER PARKING AID SENSOR LF AUTOPARK SENS LOGIC GROUND LR INNER SENSOR LR OUTER SENSOR MICRO - MIRRORS SYSTEM POWER GROUND REAR PARK AID SENS POWER (HB) REAR SENSOR GND RF AUTOPARK SENS RIGHT FRONT PARKING AID SENSOR RIGHT INNER PARKING AID SENSOR RIGHT OUTER PARKING AID SENSOR RR INNER SENSOR RR OUTER SENSOR SENSOR GROUND SOLID STATE VIO WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE
