Car Wiring Diagrams for Horn circuit for Ford F-150 XIII (2014-2018)

BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLU WIRE BODY CONTROL MODULE (BCM) CLOCK SPRING (STEERING WHEEL) FUSE 43 GRN WIRE GRN/WHT WIRE GRY WIRE HORN HORN RELAY HORN RELAY (FET) HORN RLY IN HORN SW HORN SWITCH HOT AT ALL TIMES MICRO - NCA WIRE RED WIRE STEERING COLUMN CONTROL MODULE (SCCM) STEERING COLUMN) STEERING WHEEL) VIO WIRE VIO/GRN WIRE WHT WIRE YEL WIRE YEL/RED WIRE
