Electronic power steering circuit for Ford F-150 XIII (2014-2018)
Electronic power steering circuit
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
COMPUTER DATA LINES SYSTEM
FUSE 105
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/BLU WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
MEGA FUSE
MOTOR
POWER STEERING CONTROL MODULE (PSCM)
PWR GND
VBATT
VPWR
WHT/GRN WIRE
WHT/ORG WIRE
