Ford F-150 XIII (2014-2018) dc/dc converter control module Wiring diagram
This page shows the only wiring diagram for the component.dc/dc converter control module, which is found in the car Ford F-150 XIII (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dc/dc converter control module (1 of 1)
3.5L TWIN TURBO
BLK/GRY WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
DATA LINK CONNECTOR (DLC)
DC/DC CONVERTER CONTROL MODULE
DRIVER DOOR MODULE (DDM)
DRIVER MULTI-CONTOUR SEAT MODULE
DRIVER SEAT MODULE (DSM)
FRONT SEAT CLIMATE CONTROL MODULE (SCME)
FUSE 12
FUSE 15
GATEWAY MODULE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN+
MS CAN +
PASSENGER MULTI- CONTOUR SEAT MODULE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM)
SIG GND
STANDARD CAB
TELEMATICS MODULE (W/ CREW CHIEF)
TEST CONNECTOR
TRAILER MODULE (TRM)
TRANSMISSION CONTROL MODULE (TCM)
VBATT
VIO/ORG WIRE
W/ CREW CHIEF
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Computer data lines circuit (1 of 3) -> DC/DC CONVERTER CONTROL MODULE
