Multicontour seats circuit for Ford Explorer VI facelift (2022-2024)
Multicontour seats circuit
BATTERY JUNCTION BOX (BCMC)
BLK/GRY WIRE
BLU/GRY WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
DEFLATE
DOWN
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG)
FEED
FUSE 203
FUSE 61
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
INFLATE
LEFT FRONT SEAT CONTROL SWITCH
LEFT MULTI-CONTOUR CONTROL PUMP
MODE SELECT
MS CAN +
MULTI- CONTOUR SEAT RELAY
PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH)
RIGHT FRONT SEAT CONTROL SWITCH
RIGHT MULTI-CONTOUR CONTROL PUMP
RTN
SYNC MODULE (APIM)
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
