Defoggers circuit for Ford Explorer VI facelift (2022-2024)

BATTERY JUNCTION BOX (BCMC) BLK/GRN WIRE BLK/VIO WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE CAMERA WINDSHIELD DEFROST HEATER COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) FUSE 133 FUSE 203 FUSE 50 FUSE 77 FUSE 78 FUSE 79 GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/VIO WIRE HEATED WIPER PARK HEATED WIPER PARK RELAY HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HTD MIRR HTR IMAGE PROCESSING MODULE A (IPMA) LEFT EXTERIOR MIRROR LEFT HEATED WINDSHIELD ELEMENT LEFT HEATED WINDSHIELD RELAY MS CAN + NCA WIRE PASSENGER DOOR MODULE (PDM) REAR WINDOW DEFROST GRID REAR WINDOW DEFROST RELAY RIGHT EXTERIOR MIRROR RIGHT HEATED WINDSHIELD ELEMENT/ HEATED WIPER PARK RIGHT HEATED WINDSHIELD RELAY SIG RTN VIO/ORG WIRE VIO/WHT WIRE WHT/ORG WIRE YEL/ORG WIRE YEL/VIO WIRE
