Hybrid cooling fan circuit for Ford Explorer VI facelift (2022-2024)
Hybrid cooling fan circuit
BATTERY ENERGY CONTROL MODULE (BECM)
BATTERY JUNCTION BOX (BCMC)
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC MOTOR ELECTRONICS COOLANT PUMP
FUSE 146
FUSE 169
FUSE 170
HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE
HIGH VOLTAGE BATTERY COOLANT PUMP
HIGH VOLTAGE BATTERY COOLANT TEMPERATURE SENSOR
HOT AT ALL TIMES
HOT W/ CONTACTOR RELAY ENERGIZED
MCP
RED WIRE
RED/WHT WIRE
SIGRTN
TBCP
TBCV
TBCV (FET)
TEMP
VBATT
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VPWR
WHT WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
