Ford Explorer VI facelift (2022-2024) w/ programmable driver seat Wiring diagram
This page shows the only wiring diagram for the component.w/ programmable driver seat, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ programmable driver seat (1 of 1)
3.0L TURBO 3.3L HYBRID
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
EXCEPT POLICE
FUEL DOOR MOD
FUEL DOOR RELEASE
FUSE 109
FUSE 73
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
ILL
ILLUM
LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR WINDOW CONTROL SWITCH
LIFTGATE OPEN/CLOSE
LIN 17
MS CAN +
PASSENGER DOOR MODULE (PDM)
POLICE
POWERTRAIN CONTROL MODULE (PCM)
REAR GATE TRUNK MODULE (RGTM)
RED WIRE
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT DOOR WINDOW CONTROL SWITCH
RIGHT REAR DOOR WINDOW CONTROL SWITCH
SW FRT PASS ILLUM
SW TRIM LOCK DRV
VBATT
VBATT FUEL DOOR RELEASE
VIO/ORG WIRE
W/ POWER MIRROR
W/ PROGRAMMABLE DRIVER SEAT
W/O POWER MIRROR
W/O PROGRAMMABLE DRIVER SEAT
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> W/ PROGRAMMABLE DRIVER SEAT
