Ford Explorer VI facelift (2022-2024) turbocharger bypass valve) Wiring diagrams
This page contains all the electrical diagrams for the component. turbocharger bypass valve), in which he is found in the car Ford Explorer VI facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram turbocharger bypass valve) (1 of 3)
3.0L TURBO
3.3L
AIR CONDITIONING CONTROL MODULE (ACCM)
AUXILIARY BATTERY ISOLATOR
COOLING FAN RELAY
EVAPORATIVE EMISSION (EVAP) CANISTER VENT VALVE
EVAPORATIVE EMISSION (EVAP) LEAK DETECTION CONTROL MODULE
EVAPORATIVE EMISSION (EVAP) PURGE VALVE
EXHAUST TAILPIPE ACTUATOR
FROM BATTERY JUNCTION BOX (BCMC) (DIAGRAM 9 OF 10)
FUEL FILLER DOOR LATCH
GRN WIRE
GRY WIRE
GRY/RED WIRE
LOWER ACTIVE GRILLE SHUTTER ACTUATOR
NCA WIRE
OIL PRESSURE CONTROL SOLENOID
REFUELING VALVE
TRANSMISSION HEATER COOLANT CONTROL VALVE
TURBOCHARGER BYPASS VALVE)
TURBOCHARGER WASTEGATE REGULATING VALVE SOLENOID (TCWRVS)
UPPER ACTIVE GRILLE SHUTTER ACTUATOR
VAPOR PRESSURE VALVE (VPV)
VARIABLE OIL PUMP
Go to component -> Power distribution circuit (10 of 10) -> TURBOCHARGER BYPASS VALVE)
Wiring diagram turbocharger bypass valve) (2 of 3)
3.0L TURBO
3.3L
AC-A
AC-B
AIR CONDITIONING (A/C) COMPRESSOR CONTROL SOLENOID
AIR CONDITIONING CONTROL MODULE (ACCM)
ALL WHEEL DRIVE (AWD) RELAY
ALTERNATING CURRENT (AC) POWER OUTLET SOCKET
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM)
BRN/WHT WIRE
CABIN HEATER COOLANT PUMP
CASE GND
COMPUTER DATA LINES SYSTEM
COOLANT PUMP
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE
ELECTRIC COOLANT PUMP
ENGINE CONTROLS SYSTEM
FROM BATTERY JUNCTION BOX (BCMC) (DIAGRAM 1 OF 10)
FROM BATTERY JUNCTION BOX (BCMC) (DIAGRAM 3 OF 10)
FROM FUSE 146 (DIAGRAM 3 OF 10)
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 10)
FUSE 14
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY WIRE
HIGH VOLTAGE BATTERY JUNCTION BOX
HV BATT -
LED
LIN 4
OIL PRESSURE CONTROL SOLENOID
ORG/ WIRE
ORG/GRN WIRE
ORG/WHT WIRE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
TO SPLICE 156 (DIAGRAM 10 OF 10)
TRANSMISSION HEATER COOLANT CONTROL VALVE
TURBOCHARGER BYPASS VALVE)
UPPER ACTIVE GRILLE SHUTTER ACTUATOR
VBATT
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
WAKE-UP
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (9 of 10) -> TURBOCHARGER BYPASS VALVE)
Wiring diagram turbocharger bypass valve) (3 of 3)
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/VIO WIRE
BRN/WHT WIRE
FUEL INJECTION PUMP
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
JOINT CONNECTOR 2
NCA WIRE
OIL PRESSURE CONTROL SOLENOID
PARTICULATE FILTER PRESSURE BANK 1, SENSOR 1
PARTICULATE FILTER PRESSURE BANK 2, SENSOR 1
TURBOCHARGER BYPASS VALVE)
TURBOCHARGER WASTEGATE REGULATING VALVE SOLENOID (TCWRVS)
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (7 of 12) -> TURBOCHARGER BYPASS VALVE)
