Ford Explorer VI facelift (2022-2024) transmission sensor speed resolver Wiring diagram
This page shows the only wiring diagram for the component.transmission sensor speed resolver, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission sensor speed resolver (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE SHIFT INTERLOCK
BRAKE SHIFT INTERLOCK (ON TOP OF STEERING COLUMN)
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC MOTOR
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GROUND
GRY/BRN WIRE
GRY/ORG WIRE
HIGH VOLTAGE BATTERY JUNCTION BOX
HV BATT -
INHIBIT
MOTOR U MOTOR V
MOTOR W
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/GRN WIRE
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE C (SOBDMC)
SHIELD
START INHIBIT
STEERING COLUMN LOCK MODULE
TAPED TO HARNESS
TEMP GROUND
TEMP SIGNAL
TRANSMISSION PARK DETECT
TRANSMISSION SENSOR SPEED RESOLVER
VBATT
WHT WIRE
WHT/GRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> 3.3l hybrid, a/t circuit (3 of 3) -> TRANSMISSION SENSOR SPEED RESOLVER
