Ford Explorer VI facelift (2022-2024) transfer case clutch actuator Wiring diagrams
This page contains all the electrical diagrams for the component. transfer case clutch actuator, in which he is found in the car Ford Explorer VI facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transfer case clutch actuator (1 of 3)
ALL TERRAIN CONTROL MODULE (ATCM)
ALL WHEEL DRIVE (AWD) MODULE
ALL WHEEL DRIVE (AWD) RELAY
AUTO PARK
BATTERY JUNCTION BOX (BCMC)
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
BRN/WHT WIRE
CASE GND
COMPUTER DATA LINES SYSTEM
FAD RTN
FADM
FADR
FADS
FASS +
FRONT AXLE DISCONNECT ACTUATOR
FRONT HALFSHAFT SPEED SENSOR
FUSE 203
FUSE 31
FUSE 64
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CLUSTER (IPC)
SHIELD
TCMC -
TCMP SNS A
TCMP SNS B
TCMPS +
TRANSFER CASE CLUTCH ACTUATOR
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> 2.3l turbo, awd circuit -> TRANSFER CASE CLUTCH ACTUATOR
Wiring diagram transfer case clutch actuator (2 of 3)
ALL TERRAIN CONTROL MODULE (ATCM)
ALL WHEEL DRIVE (AWD) MODULE
ALL WHEEL DRIVE (AWD) RELAY
AUTO PARK
BATTERY JUNCTION BOX (BCMC)
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
BRN/WHT WIRE
CASE GND
COMPUTER DATA LINES SYSTEM
FAD RTN
FADM
FADR
FADS
FASS +
FRONT AXLE DISCONNECT ACTUATOR
FRONT HALFSHAFT SPEED SENSOR
FUSE 203
FUSE 31
FUSE 64
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CLUSTER (IPC)
SHIELD
TCMC -
TCMP SNS A
TCMP SNS B
TCMPS +
TRANSFER CASE CLUTCH ACTUATOR
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> 3.0l turbo, awd circuit -> TRANSFER CASE CLUTCH ACTUATOR
Wiring diagram transfer case clutch actuator (3 of 3)
ALL TERRAIN CONTROL MODULE (ATCM)
ALL WHEEL DRIVE (AWD) MODULE
ALL WHEEL DRIVE (AWD) RELAY
AUTO PARK
BATTERY JUNCTION BOX (BCMC)
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
BRN/WHT WIRE
CASE GND
COMPUTER DATA LINES SYSTEM
FAD RTN
FADM
FADR
FADS
FASS +
FRONT AXLE DISCONNECT ACTUATOR
FRONT HALFSHAFT SPEED SENSOR
FUSE 203
FUSE 31
FUSE 64
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CLUSTER (IPC)
SHIELD
TCMC -
TCMP SNS A
TCMP SNS B
TCMPS +
TRANSFER CASE CLUTCH ACTUATOR
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> 3.3l hybrid, awd circuit -> TRANSFER CASE CLUTCH ACTUATOR
