Ford Explorer VI facelift (2022-2024) steering column tilt motor Wiring diagram
This page shows the only wiring diagram for the component.steering column tilt motor, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column tilt motor (1 of 1)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
DRIVER FRONT SEAT MODULE (DSM) (UNDER DRIVER'S SEAT)
FUSE 13
FUSE 30
FUSE 38
FUSE 73
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HALL EFFECT RTN
HALL EFFECT SENSE
HOT AT ALL TIMES
LEFT FRONT DOOR LOCK SWITCH
LOGIC GND
MEMORY SET SWITCH
MS CAN +
POWER DISTRIBUTION SYSTEM
PWR GND
RED WIRE
SET 1
SET 2
SET 3
STEERING COLUMN ADJUST SWITCH
STEERING COLUMN CONTROL MODULE (SCCM)
STEERING COLUMN TELESCOPIC MOTOR
STEERING COLUMN TILT MOTOR
TELESCOPE FORWARD
TELESCOPE REARWARD
TILT DOWN
TILT UP
VBATT
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
WINDOW SW RTN
YEL WIRE
YEL/GRN WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN TILT MOTOR
