Ford Explorer VI facelift (2022-2024) mirror up Wiring diagrams
This page contains all the electrical diagrams for the component. mirror up, in which he is found in the car Ford Explorer VI facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mirror up (1 of 2)
BATTERY JUNCTION BOX (BCMC)
BLIS INDICATOR
BLK WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FUSE 109
FUSE 73
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
ILLUM
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT EXTERIOR MIRROR FLASHING LED
LEFT FRONT DOOR LOCK SWITCH
LIN BUS
LOCK
LOCK SWITCH
MEM 1 SWITCH
MEM 2 SWITCH
MEM 3 SWITCH
MEM POS 1
MEM POS 2
MEM POS 3
MEMORY SET SWITCH
MIRROR FOLD IN
MIRROR HEATING
MIRROR LEFT
MIRROR RTN
MIRROR SENSE SPLY
MIRROR SENSE X
MIRROR SENSE Y
MIRROR UP
MIRRORS SYSTEM
MS CAN +
NCA WIRE
PATTERN
POLICE
PUDDLE LIGHT
RED WIRE
SIDE TURN INDICATOR
SIG RTN
SYNCRON
UNLOCK
UNLOCK SWITCH
VBATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> MIRROR UP
Wiring diagram mirror up (2 of 2)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR MODULE (DDM)
ELECTROCHROMIC MIRROR CIRCUIT
EXCEPT POLICE
FUSE 2
FUSE 73
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT EXTERIOR MIRROR FLASHING LED
LEFT FRONT DOOR WINDOW CONTROL SWITCH
LIN BUS
MIRROR FOLD IN
MIRROR LEFT
MIRROR RTN
MIRROR UP
MS CAN +
NAVIGATION SYSTEM
NCA WIRE
PATTERN
POLICE
RED WIRE
SYNCRON
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT/GRN WIRE
Go to component -> Power mirrors circuit (1 of 2) -> MIRROR UP
