Ford Explorer VI facelift (2022-2024) lighting/ siren control module Wiring diagram
This page shows the only wiring diagram for the component.lighting/ siren control module, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lighting/ siren control module (1 of 1)
3.0L TURBO
3.3L, 3.3L HYBRID
AIR CONDITIONING (A/C) CLUTCH, AIR CONDITIONING (A/C) CLUTCH FIELD COIL
AIR CONDITIONING CONTROL MODULE (ACCM)
BATTERY
BLK WIRE
BLK/VIO WIRE
BLOWER MOTOR CONTROL MODULE
BLU WIRE
CENTER CONSOLE USB CHARGE PORT
ELECTRIC MOTOR ELECTRONICS COOLANT PUMP
GEAR SHIFT MODULE (GSM)
GRN WIRE
GRY WIRE
HIGH VOLTAGE BATTERY CHILLER (CHSOV)
IGNITION COIL ON PLUG 1
IGNITION COIL ON PLUG 2
IGNITION COIL ON PLUG 3
IGNITION COIL ON PLUG 4
IGNITION COIL ON PLUG 5
IGNITION COIL ON PLUG 6
LEFT GRILLE FLASHING LED
LEFT REAR LAMP, QUARTER GLASS FLASHING LED
LIGHTING/ SIREN CONTROL MODULE
NCA WIRE
POLICE
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
REAR HEATING, VENTILATION, AIR CONDITIONING (RHVAC) CONTROL MODULE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT FOOTWELL LAMP
RIGHT GRILLE FLASHING LED
RIGHT REAR LAMP, QUARTER GLASS FLASHING LED
S191 (3.0L TURBO EXCEPT POLICE) S193 (3.0L TURBO POLICE, 3.3L, 3.3L HYBRID)
SIREN SPEAKER
TRANSMISSION
VIO WIRE
Go to component -> Ground distribution circuit (1 of 7) -> LIGHTING/ SIREN CONTROL MODULE
