Ford Explorer VI facelift (2022-2024) liftgate key switch Wiring diagrams
This page contains all the electrical diagrams for the component. liftgate key switch, in which he is found in the car Ford Explorer VI facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram liftgate key switch (1 of 2)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
AUDIO FRONT CONTROL MODULE (ACM)
AUXILIARY BATTERY
BLK WIRE
BLU WIRE
BLUNT CUT)
FUEL PUMP CONTROL MODULE
FUEL PUMP CONTROL MODULE SHIELD
GRN WIRE
GRY WIRE
HEADLAMP CONTROL MODULE (HCM)
LEFT LICENSE PLATE LAMP
LEFT VISOR FLASHING LED
LIFTGATE APPLIQUE
LIFTGATE KEY SWITCH
LIFTGATE RELEASE SWITCH
NCA WIRE
PARKING ASSIST CONTROL MODULE (PAM)
PASSENGER DOOR MODULE (PDM)
PEDESTRIAN ALERT CONTROL MODULE (PACM)
POLICE
POWER FOLD SEAT CONTROL SWITCH
REAR CLIMATE REFRIGERANT VALVE
RIGHT FRONT DOOR AMBIENT LAMP
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT DOOR WINDOW CONTROL SWITCH
RIGHT LICENSE PLATE LAMP
RIGHT SCUFF PLATE LAMP
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
RIGHT VISOR FLASHING LED
TELEMATICS CONTROL UNIT (TCU) MODULE
VIO WIRE
W/ 360 CAMERA W/O 360 CAMERA
W/ POWER LIFTGATE
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 7) -> LIFTGATE KEY SWITCH
Wiring diagram liftgate key switch (2 of 2)
BATTERY JUNCTION BOX (BCMC)
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
DETENT
FUSE 3
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
KEY UNLOCK
LIFTGATE AJAR
LIFTGATE APPLIQUE
LIFTGATE KEY SWITCH
LIFTGATE KEY UNLOCK
LIFTGATE LATCH
LIFTGATE RELEASE (FET)
LIFTGATE RELEASE SWITCH
LIFTGATE SWITCH
MICRO -
NCA WIRE
POLICE
RELEASE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Liftgate release circuit -> LIFTGATE KEY SWITCH
