Ford Explorer VI facelift (2022-2024) left second row seat cushion heater mat Wiring diagram
This page shows the only wiring diagram for the component.left second row seat cushion heater mat, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left second row seat cushion heater mat (1 of 1)
BATTERY JUNCTION BOX (BCMC)
BLK/BLU WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 118
FUSE 9
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HEATED SECOND ROW SEAT MODULE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY 1 ENERGIZED
LEFT SECOND ROW SEAT BACKREST HEATER MAT
LEFT SECOND ROW SEAT CUSHION HEATER MAT
LH HEATER IND HIGH
LH HEATER IND LOW
LH HEATER SWITCH
LR HEATED SEAT ELEMENT
LR HEATER FEED
LR NTC SENSE
MS CAN +
NCA WIRE
ORG/ WIRE
REAR HEATING, VENTILATION, AIR CONDITIONING (RHVAC) CONTROL MODULE
RED WIRE
RH HEATER IND HIGH
RH HEATER IND LOW
RH HEATER SWITCH
RIGHT SECOND ROW BACKREST HEATER MAT
RIGHT SECOND ROW SEAT CUSHION HEATER MAT
RR HEATED SEAT ELEMENT
RR HEATER FEED
RR NTC SENSE
SIG RTN
VBATT
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Rear heated seats circuit -> LEFT SECOND ROW SEAT CUSHION HEATER MAT
