Ford Explorer VI facelift (2022-2024) horn relay input Wiring diagram
This page shows the only wiring diagram for the component.horn relay input, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horn relay input (1 of 1)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CLOCKSPRING
FUSE 203
GRN/WHT WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HORN
HORN RELAY
HORN RELAY INPUT
HORN SWITCH
HOT AT ALL TIMES
NCA WIRE
POLICE PACKAGE
RED WIRE
RELAY MICRO (FET)
STEERING WHEEL)
VIO WIRE
VIO/BRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Horn circuit -> HORN RELAY INPUT
