Ford Explorer VI facelift (2022-2024) fuse 71 Wiring diagram
This page shows the only wiring diagram for the component.fuse 71, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 71 (1 of 1)
BATTERY JUNCTION BOX (BCMC)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FET
FRONT WIPER RUN/ PARK RELAY
FRT WIPER HI
FUSE 124
FUSE 13
FUSE 16
FUSE 69
FUSE 71
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LIN
LOW WASHER
MICRO -
PUMP
RAIN SENSOR (IF EQUIPPED) (CENTER FRONT OF ROOF)
REAR WASHER RELAY
REAR WINDOW WIPER MOTOR
REAR WIPER
RED WIRE
RUN/
STEERING COLUMN CONTROL MODULE (SCCM)
VBATT
VIO/RED WIRE
VPWR
W/ TRAILER TOW 13-PIN
W/ TRAILER TOW 7-PIN
WASHER CONTROL
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WIPER SWITCH
YEL WIRE
YEL/GRY WIRE
Go to component -> Wiper/washer circuit -> FUSE 71
