Ford Explorer VI facelift (2022-2024) fuse 204 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 204, in which he is found in the car Ford Explorer VI facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 204 (1 of 2)
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
FUSE 204
FUSE 22
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/BLU WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ RUN/START RELAY 2 ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
POWER STEERING CONTROL MODULE (PSCM)
VPWR
WHT WIRE
Go to component -> Electronic power steering circuit -> FUSE 204
Wiring diagram fuse 204 (2 of 2)
10-WAY POWER SEAT 6, 8-WAY POWER SEAT
4-WAY POWER SEAT
8-WAY POWER SEAT
AUXILIARY BATTERY
BATTERY
BATTERY MONITORING SENSOR
BELT-DRIVEN INTEGRATED STARTER GENERATOR
BLU/RED WIRE
BRAKE PEDAL POSITION (BPP) SWITCH
BRN/RED WIRE
BRN/WHT WIRE
COOLING FAN RELAY
DRIVER FRONT SEAT MODULE (DSM)
FUSE 108
FUSE 201
FUSE 203
FUSE 204
FUSE 208
FUSE 209
FUSE 30
FUSE 31
FUSE 36
FUSE 38
FUSE 41
FUSE 44
GENERATOR
GRN/RED WIRE
GRY WIRE
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
LEFT FRONT SEAT CONTROL SWITCH
LEFT SPOT LAMP
NCA WIRE
POLICE
POWER STEERING CONTROL MODULE (PSCM)
REAR GATE TRUNK MODULE (RGTM)
RED WIRE
RIGHT FRONT SEAT CONTROL SWITCH
RIGHT SPOT LAMP
STARTER MOTOR
TO DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER (DIAGRAM 9 OF 10)
TO RUN/START RELAY 2 (DIAGRAM 2 OF 10)
VIO/RED WIRE
VIO/WHT WIRE
W/ MEMORY
W/O MEMORY
WHT/RED WIRE
Go to component -> Power distribution circuit (1 of 10) -> FUSE 204
