Ford Explorer VI facelift (2022-2024) flasher relay Wiring diagram
This page shows the only wiring diagram for the component.flasher relay, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram flasher relay (1 of 1)
"P"
BATTERY JUNCTION BOX (BCMC)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DATA
FLASHER RELAY
FRONT WARN
FUSE 127
FUSE 160
FUSE 54
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ RUN/ START RELAY 1 ENERGIZED
ILLUM
L (-)
LIGHTING/SIREN CONTROL MODULE
MODE 3
NCA WIRE
ORG/ WIRE
PATTERN
POWER DISTRIBUTION SYSTEM
RED WIRE
RLY 8
SIREN
SIREN SPEAKER
SIREN SPEAKER 2
STEADY
TAKEDOWN
TAPED TO HARNESS
TD FLASH
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIG WAG
X (+)
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Exterior lamps circuit (1 of 7) -> FLASHER RELAY
