Ford Explorer VI facelift (2022-2024) except police w/o sync Wiring diagram
This page shows the only wiring diagram for the component.except police w/o sync, which is found in the car Ford Explorer VI facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except police w/o sync (1 of 1)
AUDIO FRONT CONTROL MODULE (ACM)
AUTO DIMMING INTERIOR MIRROR
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DM GND
DM PWR
EXCEPT POLICE W/ SYNC
EXCEPT POLICE W/O SYNC
FRONT DISPLAY INTERFACE MODULE (FDIM)
FUSE 12
FUSE 15
GRN/BLU WIRE
GRN/WHT WIRE
GRY/ORG WIRE
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
HOT AT ALL TIMES
LIFTGATE APPLIQUE
LVDS
MS CAN +
POLICE W/ AUTO-DIMMING MIRROR
POLICE W/O AUTO-DIMMING MIRROR
POWER DISTRIBUTION SYSTEM
REAR CAMERA
REAR CAMERA DRAIN
SHEILD
SHIELD
SYNC MODULE (APIM) (CENTER OF DASH)
TPA+
VBATT
VIDEO+
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component -> Rear camera circuit -> EXCEPT POLICE W/O SYNC
