Ford Explorer VI (2019-2024) left front door ambient lamp Wiring diagram
This page shows the only wiring diagram for the component.left front door ambient lamp, which is found in the car Ford Explorer VI (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door ambient lamp (1 of 1)
AUTO DIMMING INTERIOR MIRROR
BLK WIRE
BLU WIRE
BRAKE SHIFT INTERLOCK
COLUMN SHIFT
DATA LINK CONNECTOR (DLC)
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
DOOR DRIVER MODULE(DDM)
GATEWAY MODULE A (GWM)
GRN WIRE
GRY WIRE
HEADLAMP SWITCH
IGNITION SWITCH
IMAGE PROCESSING MODULE A (IPMA)
INSTRUMENT PANEL CLUSTER (IPC)
KEYLESS ENTRY KEYPAD
LEFT FRONT DOOR AMBIENT LAMP
LEFT FRONT DOOR WINDOW CONTROL SWITCH
LEFT SCUFF PLATE LAMP
LEFT SECOND ROW INTERIOR LAMP
LEFT VANITY MIRROR LAMP
LIFTGATE APPLIQUE
NCA WIRE
OVERHEAD CONSOLE
OVERHEAD CONSOLE USB CHARGE PORT
RAIN SENSOR
RIGHT SECOND ROW INTERIOR LAMP
RIGHT VANITY MIRROR LAMP
STEERING COLUMN CONTROL MODULE (SCCM)
TASK LAMP
THIRD ROW INTERIOR LAMP
TRAILER BRAKE CONTROL (TBM) MODULE
VIO WIRE
W/ KEYLESS ENTRY
W/ START/STOP
W/O KEYLESS ENTRY
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (5 of 7) -> LEFT FRONT DOOR AMBIENT LAMP
