Second row folding seat circuit for Ford Explorer V facelift (2015-2018)
Second row folding seat circuit
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BODY CONTROL MODULE (BCM)
DEMAND LP/ BATTERY SAVER RELAY
FUSE 1
FUSE 98
GRN/BRN WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
LEFT SECOND ROW POWER RELEASE SEAT MOTOR
LEFT SECOND ROW SEAT CONTROL SWITCH
MICRO -
RELAY MODULE
RIGHT SECOND ROW POWER RELEASE SEAT MOTOR
RIGHT SECOND ROW SEAT CONTROL SWITCH
YEL/GRN WIRE
YEL/RED WIRE
