Car Wiring Diagrams for Rear heated seats circuit for Ford Explorer V facelift (2015-2018)

BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM DRV BATT FUSE 11 FUSE 36 FUSE 5 GRN WIRE GRN/BRN WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED ILLUMINATION LEFT REAR SEAT BACKREST HEATER MAT LEFT REAR SEAT CUSHION HEATER MAT LH HIGH LED LH LOW LED LH SYS LO/HI/OFF LH SYS LO/HI/OFF(V-) LR SEAT NTC LR HEATER FD MS CAN + NCA WIRE PASS BATT POLICE POWER DISTRIBUTION SYSTEM REAR HEATED SEAT MODULE (UNDER RIGHT REAR SEAT) REAR HEATING, VENTILATION, AIR CONDITIONING CONTROL MODULE (RHVAC) RH HIGH LED RH HIGH LED(+) RETURN RH LOW LED RH SYS LO/HI/OFF RH SYS LO/HI/OFF(V-) RR SEAT NTC RIGHT REAR SEAT BACKREST HEATER MAT RIGHT REAR SEAT CUSHION HEATER RR HEATER FD RUN/START VIO WIRE VIO/ORG WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE
