Car Wiring Diagrams for Multicontour seats circuit for Ford Explorer V facelift (2015-2018)

BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM DEFLATE DEFLATE INFLATE DEMAND LP/ BATTERY SAVER RELAY DOWN DRIVER MULTI-CONTOUR SEAT MODULE (SCMG) DRIVER SIDE FRONT SEAT CONTROL SWITCH FEED FUSE 92 GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES INFLATE LEFT MULTI-CONTOUR CONTROL PUMP MODE SELECT MS CAN + MULTI- CONTOUR SEAT RELAY PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH) PASSENGER SIDE FRONT SEAT CONTROL SWITCH RELAY MODULE RIGHT MULTI-CONTOUR CONTROL PUMP RTN SYNC 2 SYNC 1 SYNC MODULE (APIM) VBATT VIO/ORG WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE
