Car Wiring Diagrams for Electronic power steering circuit for Ford Explorer V facelift (2015-2018)

BATTERY JUNCTION BOX (BJB) BLK/VIO WIRE BLU/ORG WIRE COMPUTER DATA LINES SYSTEM FUSE 102 FUSE 31 GRN/BLU WIRE GRN/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN OR START HS CAN+ INSTRUMENT PANEL CLUSTER (IPC) POWER STEERING CONTROL MODULE (PSCM) REAR OF ENGINE COMPT) VPWR WHT/GRN WIRE
