Ford Explorer V facelift (2015-2018) third row power point Wiring diagram
This page shows the only wiring diagram for the component.third row power point, which is found in the car Ford Explorer V facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram third row power point (1 of 1)
ALL WHEEL DRIVER (AWD) RELAY MODULE
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
AUXILIARY BLOWER MOTOR CONTROL
BLK WIRE
GRN WIRE
GRY WIRE
HIGH MOUNTED STOP LAMP
LEFT LICENSE PLATE LAMP
LIFTGATE APPLIQUE
LIFTGATE KEY SWITCH
LIFTGATE LATCH
LIFTGATE LATCH/UNLATCH ASSEMBLY
LIFTGATE REAR CONTROL SWITCH
LIFTGATE RELEASE SWITCH
LIFTGATE/ TRUNK MODULE (LTM)
NCA WIRE
PLATINUM/LTD/SPORT
POLICE
POWER FOLD SEAT MODULE (PFSM)
RADIO TRANSCEIVER MODULE (RTM)
REAR HEATED SEAT MODULE
REAR WINDOW DEFROST GRID
REAR WINDOW WIPER MOTOR
RIGHT LICENSE PLATE LAMP
RIGHT REAR SEAT CUSHION HEATER
RIGHT SECOND ROW POWER RELEASE SEAT MOTOR
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE
THIRD ROW POWER POINT
THIRD ROW SEAT CONTROL SWITCH
W/ MANUAL LIFTGATE
W/ PLATINUM
W/ POWER LIFTGATE
Go to component -> Ground distribution circuit (6 of 7) -> THIRD ROW POWER POINT
